Low Speed Wire Drawing Machine

The machine using materials of Polypropylene(PP) or high density Polyethylene(HDPE), through heating, extruding, splitting the film into tapes, stretching and forming flat tapes. Then winding on the bobbins by winder, finally put the bobbins with tapes on circular loom for weaving.

Performance and characteristics:

*The machine using materials of Polypropylene(PP) or high density Polyethylene(HDPE), through heating, extruding, splitting the film into tapes, stretching and forming flat tapes. Then winding on the bobbins by winder, finally put the bobbins with tapes on circular loom for weaving.

*After improving many times, the machine can use 100%recycling material, powder and granule material to produce tapes. The screw and cylinder of extruder are made of 38CrMoA1A alloy steel, the hardness is over HV950 after nitriding treatment. Helical gear reducer made of 20CrMnTi alloy steel is applied to the gear reducer of extruder. The traction devices adopts touch screen to change speed which enable stable drawing.

Technical Data:

Model	Diameter of screw(mm)	Rotational speed of screw (r/min)	Width of Die(mm)	Model of reducer	Motor power of extruder (kw)	Heating power of extruder (kw)	Power of driving motor (kw)	Heating power of the oven (kw)	Drawing rate	Production capacity (kg/h)	Drawing speed(m/min)	Installation dimension (L×W×H)mm	Weight (kg)
SJ-FS115/B800	115	25-75	800	250	30	36	7.5	15	4-12	50-100	50-150	11300×1500×1300	6500
SJ-FS120/B1000	120	23-70	1000	250	30	43	7.5	20	4-12	60-120	50-150	14700×1750×1300	8000
SJ-FS120/B1200	120	23-70	1200	250	30	47	7.5	24	4-12	70-140	50-150	16500×2050×1300	10000
SJ-FS135/B1600	135	22-65	1600	280	37	77	7.5	30	4-12	90-180	50-150	20000×2600×2200	16000
SJ-FS140/B1800	140	22-65	1800	280	37	80	11	30	4-12	100-200	50-150	20000×2950×2200	17000
SJ-FS145/B2000	145	20-60	2000	300	45	86	11	30	4-12	110-240	50-150	21000×3400×2200	20000
SJ-FS150/B2200	150	20-60	2200	300	55	86	11	30	4-12	120-260	50-150	22000×3700×2200	21500
SJ-FS150/B2400	150	20-60	2400	300	55	92	15	32	4-12	140-280	50-150	22000×4000×2200	23000
SJ-FS160/B2600	160	20-60	2600	315	75	96	15	32	4-12	140-300	50-150	23000×4400×2500	24500
SJ-FS160/B2800	160	20-60	2800	315	75	106	15	34	4-12	160-320	50-150	23000×4600×2500	25000
SJ-FS160/B3000	160	20-60	3000	315	90	106	15	34	4-12	160-340	50-150	24000×4800×2500	26500
SJ-FS170/B3200	170	20-60	3200	375	90	112	18	36	4-12	180-350	50-150	25000×5000×2500	27500
SJ-FS170/B3500	170	20-60	3500	375	110	118	18	36	4-12	200-360	50-150	25000×5200×2500	29000
SJ-FS180/B3800	180	20-60	3800	420	110	118	18	45	4-12	200-380	50-150	25000×5500×2500	32000
SJ-FS180/B4000	180	20-60	4000	420	132	145	22	50	4-12	350-450	50-150	25000×6000×2500	35000
SJ-FS200/B5000	200	20-60	5000	450	160	155	30	60	4-12	500-600	50-150	26000×6200×2500	40000
SJ-FS210/B5800	210	20-60	5800	450	185	165	30	70	4-12	500-700	50-150	26000×6200×2500	45000
