Auto coldcutting and liner bag inserting and bottom sewing for pp woven bag to save the labor.
Touch screen (Delta), PLC (OMRON), servo motor (ELESY) to control the length of bag precisely
3. Auto counting, integrated feeding.

Auto coldcutting and liner bag inserting and bottom sewing for pp woven bag to save the labor.
Touch screen (Delta), PLC (OMRON), servo motor (ELESY) to control the length of bag precisely
3. Auto counting, integrated feeding.
4. Air shaft ,Fabric rolls auto electric lifting, convenient operation.
5. Voltage is 415V / 50HZ / 3PHASE
EPC system, auto rectify control, which means web alignment unit,also have tension control system
The sewing machine head(Shangpeng brand)doublestitching, four thread
software is bilingual in Chinese and Englishor other language.
Bag collecting by air cylinder
inner PE bag bottom will be hot sealing, inner and outer bags can be stitching together or separated

Model	KWT-800
Cutting mode	Cold and hot, two functions on one machine
Max. Diameter Of Unwinding Roll (Mm)	1200mm
Max. Width of PP Woven Fabric(Mm)	750mm
Max. Width of PE Film(Mm)	800mm
Max Cutting Length(Mm)	1250mm
PE bag wider than PP bag(Mm)	20mm
Cutting Precision(Mm)	+-1.5
Folding width	16-30mm
Production Capacity	About 28-32pcs/min
Installing Dimensions (LWH)(Mm)	700060001600mm
Weight (Kg)	3000kgs

Main Configuration Brand List:
