| Name | Qty. | Parameter | Device |
| 1、Extruder | One set | 1、inverter control 2、Hard tooth surface gear box with cooling system 3、Screw Material：38CrMoAlA4、Heating Material：Casting AL |
|
| 1).a).Main power | 75 Kw | ||
| b).Gear box type | 250型 | ||
| c).Dia.of screw,ratio of L/D | Φ75mm，L/D:33:1 | ||
| d).Rotate speed of screw | 20-120r/min | ||
| 2).T Die head | One set | 850 | “1.Material：First grade tools steel 2、Surface treating；outside and inner plating Cr3、Heating method：stainless steel pipe inner heating “ |
| a).size | |||
| 3).Filter exchanger device | One set | 1、Exchange filter method：Autobelt changer | |
| 2、Cooling tank | One set | “1、Material：Stainless 2、Specialty：vertial movable for easy cleaning model chip。” |
|
| a).Overall size（LⅹW） | |||
| 3、Take-up，cutting and pulling device | One set | “1、Frequency conversion 2、Knife rest for cutting film：Can be movable “ |
|
| a).Take-up and pulling motor | 3kw,4kw | ||
| b).Size of rubber roller | Φ180ⅹ850 | ||
| 4、Recycled hot Blast oven | One set | “1、Double layer recycled hot blast oven. 2、Heating with electrical pipe heater. 3、Equiping wind power controller to adjust the wind. 4、Specially designed passage，making hot wind distribute” |
|
| a).Length | 4000mm | ||
| b).Heating power | 24kwⅹ2 | ||
| c).Motor power | 4kwⅹ2 | ||
| 5、Six rollers take-off unit6 | One set | “1、Inverter control speed 2、Surface treating：plating Cr 3、Guiding roller at front，safty and easy operate 4、Strap transfer 5、one pc cooling water roller 6、Fram using Casting steel” |
|
| a).Motor power | 15kw,5.5kw | ||
| b).Steel roller size | Φ315ⅹ850mm | ||
| c).Line speed（Max） | 400m/min | ||
| 6、Winders | 140 | “1、Magenetic plate transmission 2、Two pair synchronizing wheel transmission，Stability running and low noise” |
|
| a).Type | |||
| b). Spindle Motor power | 180W | ||
| c).Bobbin size（inner DIA.ⅹL） | Φ38ⅹ230mm | ||
| 7、Waste yarn recycling device | One set | “1、Including：pipe and wasterage case 2、absorb from up side” |
|
| a).Motor power | 7.5kw | ||
| 8、Crusher and recycling device | One set | Including：pipe and wasterage case | |
| a).Crusher motor power | 2.2kw | ||
| b).Fan power | 1.5kw | ||
| c). Mixer power | 0.75kw | ||
| 9、Auto feeder | One set | ||
| a).Capacity | 150kg/h | ||
| 10、Electric control system | One set | 1、GGD Electeucal box one set，（others see electrical parts list） |
