Auto hotcutting and bottom sewing for pp wovenbag to save the labor.(straight cutter or zigzag cutter)
Touch screen (Delta brand), PLC (OMRONbrand),Inverter(Delta brand),servo drive and motor (Delta brand) to control the length of bag precisely
The mouth of the bag is easy open after hotcutting

Auto hotcutting and bottom sewing for pp wovenbag to save the labor.(straight cutter or zigzag cutter)
Touch screen (Delta brand), PLC (OMRONbrand),Inverter(Delta brand),servo drive and motor (Delta brand) to control the length of bag precisely
The mouth of the bag is easy open after hotcutting
Auto countingfunction
Unwinding unit can lift the fabric rolls electrically, convenient operation.
voltage is 380V / 50HZ / 3PHASE
the sewing machine head( shangpeng brand) with singleor double needlestitching
software is bilingual in Chinese and Englishor French

Model	KWY-800*1350
Max. Diameter Of Unwinding Roll (Mm)	1200mm
Max. Cutting Width(Mm)	300-800mm
Max Cutting Length(Mm)	400-1350mm
Cutting Precision(Mm)	+-1
Production Capacity	40-60pcs/min
Gross Power	7kw
Installing Dimensions (LWH)(Mm)	600060001500mm
Weight (Kg)	2000kgs

Serial number	ITEM	BRAND
1	servo motor and driver	DELTA
2	PLC	OMRON
3	touch screen	DELTA
4	frequency converter inverter	DELTA
5	sewing machine model GK20-DN-2S	SHANGPENG
6	Color code tracker	PANASONIC
7	cylinder	AirTAC
8	solenoid valve	AirTAC
